Jinan Moon Refrigeration,covering an area of 20,000 sqm land, is a manufacturer, designer and installer for cold room in Jinan City,China.
 |
| Quantity: | |
|---|---|
Model: EMB7065M5ZH
Power supply: 380V/3Ph/50Hz
Refrigerant: R404A
Cooling capacity: 6.5 HP
Evap. model: EEC2416
Application range: 0 to +10 °C
Cold room: 100 to 175 m³
Weight: 325 Kg
Unit dimensions: A(810 mm) B(1570 mm) C(1650 mm) D(650 mm) F(635 mm) G(1880 mm) K(2065 mm)
Unit+packing dimensions: A(1150 mm) B(1750 mm) C(2155 mm)
Corte panel cut dimensions: H(1910 mm) L(725 mm)
Designed for medium-sized cold storage rooms operating at medium to low temperatures, this semi-industrial monoblock refrigeration unit is wall-mounted. It incorporates an energy-saving smart integrated refrigeration system and includes automatic hot gas defrost.
- Automatic defrosting by hot gas
- Pre-charged with refrigerant
- Liquid glass
- Magnetothermic protection.
- Medium temperature and low temperature
- medium size cold rooms
- Wall-mounted type installation
1) .Only dig a hole on the wall panel,then locate the monoblock inside the wall panel.No need connect copper pipes between condensing unit and evaporator.
2) .No need professional refrigeration engineer to install and run the unit,which can save your installation cost.
PACKAGE
